Challenges of Maintaining PCB Signal Integrity in High-Speed Designs

Ultra-high signal speeds demand detailed consideration of the third dimension in PCB design, including via structures and layer stacks. Today I’m going to focus on the challenge. In my two subsequent posts, I’ll be reviewing what PCB designers can do to meet that challenge.

Mainstream High-Speed Signals

Not long ago, third dimension issues didn’t figure too much in high-speed design calculations; but signals have become so fast that those vias don’t affect them the same way they did before. Those really fast signals have become part of super-common bus standards that are used in all kinds of products.

It’s a PCB design issue that we can’t avoid. Luckily, there are ways not just to address this issue, but to optimize performance at the same time.

Effects of Vias on PCB Signal Integrity in High-Speed Designs

Layer changes can slow signals down or distort them. Their effects depend (amongst other things) on:

• Via geometry
• Where vias are placed within the routing
• Shape and speed of signals
• Other nearby items that couple to vias

So vias don’t always distort signals in the same way and neither does the same via always introduce the same delay.

New Via Technology Threshold

A key breakpoint is reached when a signal is so fast that the routing that carries it starts to behave as a network of transmission lines. When this happens, engineers must take positive steps to make sure signals arrive in good shape.

For mainstream digital designs, that breakpoint was reached decades ago for routing in the XY plane. That’s why we’ve long had controlled routing topology and reference ground and power planes. But now we’ve reached the point where we need to do the same in the third dimension. Standards-based bussing means that this can happen even on a board that doesn’t run particularly quickly.

If you’d like to see me describe all that with the help of a sheet of hardboard, you can watch this short movie.

See you again in Part 2 where I look more at how to use vias to maintain PCB signal integrity under these high-speed 3D conditions.
