Working in either two or three dimensions, E3.panel allows engineers to layout components inside panel enclosures. Intelligent automatic snapping points allow parts to be easily placed in their correct location, and with keep-out and height restrictions it is also possible to prevent clashes. The ease-of-use means electrical engineers do not need to understand M-CAD tools.
A direct integration of 3D cabinet layout and electrical schematics enabling a flexible design process starting with cabinet layout or schematic design.
Leverage desgin data to generate outputs for wire lists, which includes route and length information.
Direct use of manufacturing data to drive manufacturing equipment such as wire preparation machinery and drilling, punching and cutting tools.
E3.panel, logiciel de conception d'armoire électrique, permet aux ingénieurs de disposer des composants à l'intérieur d'enceintes à panneaux en 3D et en 2D.
E3.cable, logiciel de conception de câbles électriques, est utilisé pour la conception et la documentation de plans de câbles et de dispositions de faisceaux
E3.schematic offre aux ingénieurs électriciens une solution conviviale pour la conception et la documentation des systèmes de commande électriques, notamment des schémas, des plans de bornes et des PLC.
This webinar will provide details and demonstrations of the various tools available to help support the manufacturing automation of cabinet / panel designs.
